Syslog ingestion

ActiveGate version 1.295+

Syslog, short for system logging protocol, is a logging mechanism that enables system administrators to oversee and control log files from various system components, such as network devices, Linux host syslog, syslog servers, or other syslog producers.

This guide shows you how to configure your Environment ActiveGate on Linux to collect syslog logs in your network and ingest them to Dynatrace.

Prerequisites

Environment ActiveGate version 1.295+ on Linux installed to monitor remote technologies.
Your network devices have the syslog enabled or you have other syslog producers configured in your network. Refer to RFC3164 and RFC5424 for details. Dynatrace supports a wide variety of syslog implementations, including RSysLog, Syslog-NG, NXLog, and others.

Who is it for?

This guide is intended for network and Dynatrace admins who are tasked to enable the syslog log ingestion into Dynatrace.

Enable syslog ingestion

Enabling syslog log ingestion requires you to:

Deploy Environment ActiveGate in a place ensuring the connectivity between ActiveGate and monitored devices.
Enable syslog ingestion on ActiveGate.
optional in some cases, you'll need to adapt the default syslog receiver configuration.

Deploy Environment ActiveGate.

See instructions for Linux. Use the remote technologies monitoring purpose.
Enable syslog ingestion on your ActiveGate.

Edit the /var/lib/dynatrace/remotepluginmodule/agent/conf/extensionsuser.conf file and add the following flag:
```
syslogenabled=true
```

optional Edit the syslog receiver configuration.

ActiveGate uses an embedded Dynatrace OpenTelemetry Collector instance and stores the receiver configuration in the /var/lib/dynatrace/remotepluginmodule/agent/conf/syslog.yaml file. The Collector is installed by default.

Use this configuration only for syslog ingestion.

If your syslog producers use the default ports per supported protocols, your syslog-enabled ActiveGate should receive syslog records right away.

You only need to modify the configuration if your syslog producers cast events on custom ports.

receivers:
  syslog/udp:
    udp:
      listen_address: '0.0.0.0:514'
      add_attributes: true
    protocol: rfc5424
    operators:
      - type: syslog_parser
        protocol: rfc5424

  syslog/tcp:
    tcp:
      listen_address: '0.0.0.0:601'
      add_attributes: true
    protocol: rfc5424
    operators:
      - type: syslog_parser
        protocol: rfc5424
#  syslog/tcp_tls:
#    tcp:
#      listen_address: "0.0.0.0:6514"
#      tls:
#        cert_file: "/absolute/path/to/server.crt"
#        key_file: "/absolute/path/to/server.key"
#    protocol: rfc5424
#    operators:
#      - type: syslog_parser
#        protocol: rfc5424

#DO.NOT.MODIFY
exporters:
  otlphttp/syslog: ${file:syslogendpoint.yaml}

processors:
  batch:
    send_batch_size: 512
    send_batch_max_size: 1024
  transform:
    log_statements:
      - context: log
        statements:
          - set(body, attributes["message"])
  attributes:
    actions:
      - key: net.host.name
        action: delete
      - key: net.peer.name
        action: delete
      - key: net.peer.port
        action: delete
      - key: net.transport
        action: delete
      - key: net.host.ip
        action: delete
      - key: dt.ingest.port
        from_attribute: net.host.port
        action: upsert
      - key: dt.ingest.source.ip
        from_attribute: net.peer.ip
        action: upsert
      - key: net.peer.ip
        action: delete
      - key: net.host.port
        action: delete
      - key: syslog.hostname
        from_attribute: hostname
        action: upsert
      - key: hostname
        action: delete
      - key: syslog.facility
        from_attribute: facility
        action: upsert
      - key: facility
        action: delete
      - key: syslog.priority
        from_attribute: priority
        action: upsert
      - key: priority
        action: delete
      - key: syslog.proc_id
        from_attribute: proc_id
        action: upsert
      - key: proc_id
        action: delete
      - key: syslog.version
        from_attribute: version
        action: upsert
      - key: version
        action: delete
      - key: syslog.appname
        from_attribute: appname
        action: upsert
      - key: appname
        action: delete
      - key: message
        action: delete

service:
  telemetry:
    metrics:
      level: none
  pipelines:
    logs/udp:
      receivers: [syslog/udp]
      processors: [transform, attributes, batch]
      exporters: [otlphttp/syslog]
    logs/tcp:
      receivers: [syslog/tcp]
      processors: [transform, attributes, batch]
      exporters: [otlphttp/syslog]
#    logs/tcp_tls:
#      receivers: [syslog/tcp_tls]
#      processors: [transform, attributes, batch]
#      exporters: [otlphttp/syslog]

You can also modify the default configuration if you want to group a set of various devices by configuring them to use a specific port. For example, you can enrich your syslog events cast on specific TCP ports using the configuration as in the example below

receivers:
 syslog/f5:
    tcp:
      listen_address: "0.0.0.0:54526"
    protocol: rfc5424
    operators:
      - type: add
        field: attributes.log.source
        value: syslog
      - type: add
        field: attributes.dt.ip_addresses
        value: "1xx.xx.xx.xx1"
      - type: add
        field: attributes.instance.name
        value: "ip-1xx-xx-x-xx9.ec2.internal"
      - type: add
        field: attributes.device.type
        value: "f5bigip"
 syslog/host:
    tcp:
      listen_address: "0.0.0.0:54527"
    protocol: rfc5424
    operators:
      - type: add
        field: attributes.log.source
        value: syslog
      - type: add
        field: attributes.device.type
        value: "ubuntu-syslog"

Note: Do NOT modify the exporter configuration. The default configuration points to the embedded Collector.

For more information on syslog receiver configuration, see Ingest syslog data.

Verify the syslog ingestion is enabled.

After you enable syslog ingestion, check the following log files to verify it:

Open the newest ruxit_extensionmodule_*.log log file in the extensions log directory:
- Linux: /var/lib/dynatrace/remotepluginmodule/log/extensions
It should contain the following line:
```
Otel syslog enabled: true
```
Enable syslog on the devices you want to monitor.

The way you enable syslog depends on the device and its platform, refer to specific documentation for details.

Example Configure Rsyslog on Linux Ubuntu to forward syslog logs to a remote server.

Add the following line to the syslog daemon configuration file (/etc/rsyslog.conf)
- UDP
```
*.* @<ActiveGate host IP>:514
```
- TCP
```
@@ @<ActiveGate host IP>:601
```
*.* or @@ instruct the daemon to forward all messages to the specified ActiveGate listening on the provided port and IP address. <ActiveGate host IP> needs to point to the IP address of a syslog-enabled ActiveGate.

For more examples, see Syslog via OpenTelemetry Collector

Verify ActiveGate receives the syslog events.

After your syslog producers start to cast log records, open the latest dynatracesourceotelcollector.*.log file in /var/lib/dynatrace/remotepluginmodule/agent/datasources/otelSyslog.

If ActiveGate receives the log records you should see entries as in the example below:

[otelSyslog][otelSyslog][37448][err]LogRecord #3
[otelSyslog][oteiSyslog][37448][err]ObservedTimestamp: 2024-05-06 @9:52:10.6748723 +8000 UTC
[otelSyslog][otelSyslog][37448][err]Timestamp: 2624-05-@6 11:52:16 +90e0 UTC
[otelSyslog][otelsyslog][37448][err]SeverityText: info
[otelSyslog][otelSyslog][37443][err]SeverityNumber: Info(9)
[otelSyslog][otelSyslog][37448][err]Body: Str(<30>May 6 11:52:10 SOME-HOST systemd[1]: Finished    Load Kernel Module fuse.)
[otelSyslog][otelSyslog][37448][err]Attributes:
[otelSyslog][otelSyslog][37448][err]    -> priority: Int(3)
[otelSyslog][otelSyslog][37448][err]    -> facility: Int(3)
[otelSyslog][otelSyslog][37448][err]    -> appname: Str(systemd)
[otelSyslog][otelSyslog][37448][err]    -> proc_id: Str(1)
[otelSyslog][otelSyslog][37443][err]    -> log: Map({“source": “syslog"})
[otelSyslog][otelSyslog][37443][err]    -> hostname: Str(SOME-HOST)
[otelSyslog][otelSyslog][37443][err]    -> message: Str(Finished Load Kernel Module fuse.)
[otelSyslog][otelSyslog][37448][err]Trace ID:
[otelSyslog][otelSyslog][37448][err]Span ID:
[otelSyslog][otelSyslog][37443][err]Flags: 0

For more information on troubleshooting the syslog receiver, see Collector troubleshooting.

Next steps

After you enable the integration, the syslog-ingested events are enriched with the host-specific attributes and become available in Grail for Davis® AI-based data analysis, log processing, or querying via DQL.
